ALTERNATIVE C: Business Access Transit (BAT) Lanes
Carpenter Road to Hewitt Road
Carpenter Road to Hewitt Road
Carpenter Road to Hewitt Road
Hewitt Road to Oakwood Street
Hewitt Road to Oakwood Street
Hewitt Road to Oakwood Street
Design Features
Reduction to three travel lanes and dedicated transit lanes from Carpenter Road to Hewitt Road
Private vehicle access to the transit lane to allow right turns into businesses
Contiguous shared-use pathways on both sides of the street that are proposed to be shared by pedestrians and bicyclists
Enhanced transit stop infrastructure
Transit signal priority at key intersections
Requires significant ROW
Carpenter Road to Hewitt Road
Hewitt Road to Oakwood Street
Design Features
Reduction to three travel lanes
On-street buffered bike lanes
On-street parking to be added in the Mansfield business area, as appropriate
Sidewalk buffer landscaping and street trees
Contiguous sidewalks throughout
Minimal ROW needed
